Vandal Resistant Telephone YT103-SIP
- Robust stainless steel housing
- Protection level IP65
- HD calls with advanced noise cancellation
- Corrosion-resistant coating
- CE, FCC, RoHS, IK10, IP68, ISO9001 standards
Main Features
Designed by extreme prison environments, the telephone adopted a robust stainless steel shell,with the anti-corrosion coating enclosure.
It is adapt to harsh conditions such as high humidity,moisture, dust,shock, vibration,saltwater, and physical abuse.
The vandal-proof series telephone is specifically designed for environments prone to vandalism,providing reliable communication for locations such as parking lots, prisons, airports, railways, metro stations,bank, ATMs, platforms, hospitals, police stations, shopping malls, and stadiums.
- Handset made from PC and ABS composite materials
- Includes a tensile steel rope with over 200KG strength
- Vandal-proof telephone without keyboard
- Orange color,optional according customized request
- The handset supports hearing aid compatibility (HAC)
- Desk mounting Installation,easy to install
Applications
IP telephony system is an efficient and convenient communication solution that utilizes an Internet connection to enable voice calls and other communication services. Compared to traditional telephone systems, IP telephony offers greater efficiency and flexibility.
Product Video
Technical Specifications
| Basic Features | |
| Waterproof Rate | IP65 |
| Enclosure Material | Stainless steel casing Powder coating treatment Outdoor UV protection |
| Color | Orange ( default) |
| Communication mode | Full duplex |
| Handset material | ABS+PC, stainless steel armored telephone cable |
| Keypad | Without |
| Power supply | DC 12 V-24V/1.5A |
| Power consumption | Standby:1.5W, Working power: 1.8W (excluding amplification) |
| Working temperature | Operating temperature: -40°C to + 70°C Storage temperature: -40°C to +75°C |
| Mean Time Between Failures | More than 50,000 hours |
| VoIP Features | |
| Protocol | SIP 2.0(RFC3261) |
| Registration line | 6 lines at same time |
| Codec | G.711A/u, G.7231 high/low, G.729, G.722,G.726 |
| Echo cancellation | Support G.168, Hands-free :max 96 millisecond |
| Network | 10/100 Mpbs WAN/LAN: Support bridge mode Support virtual LAN Support stun NAT penetration |
Product Application
Maritime
Highway / Tunnel
Railway
Power - Station
Mining industry
Industrial park
Dimensions
| Package | |
| Unit size | 240*100*150 (mm) |
| Packaging materials | corrugated box, pearl cotton lining |
| Weight | Net weight : about 3 KG / Gross Weight :4 KG |
