Explosion Proof Telephones YTEX302-SC-SIP
- Aluminum alloy die-casting enclosure
- Protection level IP68
- HD calls with advanced noise cancellation
- Corrosion-resistant coating
- CE, FCC, RoHS, IK10, IP68, ISO9001 standards
Main Features
Designed by extreme environments, The telephone adopted a robust die-cast aluminum shell with a weatherproof, polyurethane-coated enclosure.
It is adapt to harsh conditions such as high humidity, dust,shock, vibration,saltwater, and physical abuse.
Very suitable for outdoor and industrial application, including highways, tunnels, wind farms, production areas, chemical, Power plants, and heavy machinery like container cranes and ship loaders.
- Stainless steel emergency button fast dial and communication
- Qualified telephone speaker and mirophone provide HD sound communication
- External Speaker can increases ringing volume to 110 dB and can broadcast messages
- The handset supports hearing aid compatibility (HAC)
- Magnetic reed hook switch to reduce wear-prone parts
- With magnetic gravity door cover,supports wall mounting with mounting bar
Applications
IP telephony system is an efficient and convenient communication solution that utilizes an Internet connection to enable voice calls and other communication services. Compared to traditional telephone systems, IP telephony offers greater efficiency and flexibility.
Product Video
Technical Specifications
| Basic Features | |
| Ex mark | Ex d ib IIB T6 Gb |
| Waterproof Rate | IP68 |
| Ringing Sound Level | ≥80 db at 1 meter |
| External Speaker | >110 db at 1 meter ( optional) |
| Noise cancellation | Optional |
| Full-duplex communication | Support |
| Enclosure Material | Aluminium alloy die-casting Powder coating treatment Outdoor UV protection |
| Color | Red ( default) |
| Emergeny button | One Stainless Steel Button |
| Power supply | DC 12 V/2A or POE |
| Power consumption | Standby:1.5W, Working power: 3W (without external speaker) |
| Working temperature | Operating temperature: -40°C to + 70°C Storage temperature: -40°C to +75°C |
| Mean Time Between Failures | More than 50,000 hours |
| VoIP Features | |
| Protocol | SIP 2.0(RFC3261) |
| Registration line | 2 lines at same time |
| Codec | G.711A/u, G.7231 high/low, G.729, G.722,G.726 |
| Echo cancellation | Support G.168, Hands-free :max 96 millisecond |
| Network | 10/100 Mpbs WAN/LAN: Support bridge mode Support virtual LAN Support stun NAT penetration |
Product Application
Maritime
Highway / Tunnel
Railway
Power - Station
Mining industry
Industrial park
Dimensions
| Package | |
| Unit size | 373*282*137(mm) |
| Packaging materials | corrugated box, pearl cotton lining |
| Weight | Net weight : about 8 KG / Gross Weight :10 KG |
