Emergency intercom YT501-SC-IW-SIP
- 304 Stainess Steel Enclosure
- Protection level IP65
- HD calls with advanced noise cancellation
- Corrosion-resistant coating
- CE, FCC, RoHS, IK10, IP68, ISO9001 standards
Main Features
Constructed from stainless steel with a brushed surface finish, the emergency telephones are engineered to meet stringent quality standards, providing strong protection against vandalism and guaranteeing stable communication at all times.
The series has undergone salt spray testing, ensuring outstanding resistance to moisture and corrosion, making it highly reliable in harsh environments.
Designed for quick installation, the wiring access is positioned at the back of the unit to minimize the risk of tampering.
Suitable for use in locations such as parking areas, elevators, hotels, entrances, railway and metro platforms, hospitals, police stations, ATMs, and various outdoor facilities.
- Hands-free full-duplex intercom with one speed dial button
- The handset supports hearing aid compatibility (HAC)
- High Anti-noise Performance
- Extreme temperatures ranging from 65℃ to -40 ℃.
- Built-in speaker and microphone pole for hands-free calling and receiving announcements
- Wall-mounted Design,easy to installation
Applications
IP telephony system is an efficient and convenient communication solution that utilizes an Internet connection to enable voice calls and other communication services. Compared to traditional telephone systems, IP telephony offers greater efficiency and flexibility.
Product Video
Technical Specifications
| Basic Features | |
| Waterproof Rate | IP65 |
| Noise cancellation | Optional |
| Full-duplex communication | Support |
| Enclosure Material | Aluminium alloy |
| Power supply | DC 12 V/2A or Switch output: 33-60V |
| Power consumption | Standby:1.5W, Working power: 1.8W (without amplification) |
| Operating Temperature & Humidity | -40°C to +65°C |
| Mean Time Between Failures | More than 50,000 hours |
| VoIP Features | |
| Protocol | SIP 2.0(RFC3261) |
| Registration line | 6 lines at same time |
| Codec | G.711A/u, G.7231 high/low, G.729.G.722, G.726 |
| Echo cancellation | Supports G.168, Handsfree up to 96ms |
| Network | 10/100 Mpbs WAN/LAN: Support bridge mode Support virtual LAN Support stun NAT penetration |
Product Application
Maritime
Highway / Tunnel
Railway
Power - Station
Mining industry
Industrial park
Dimensions
| Package | |
| Unit size | 120*205*40(mm) |
| Packaging materials | corrugated box, pearl cotton lining |
| Weight | Net weight : about 2 KG / Gross Weight :3 KG |
